1. Product Features
|
Main Function
|
² Android 8.0 embedded system; ² Support 20-point touch writing experience to meet the needs of different users; ² Android whiteboard smart pen for writing, with its own pen tip, restore notes; ² Scan the code of the meeting to easily take away the summary of the meeting, making data sharing more convenient; ² Support continuous annotation under any channel; ² Support custom boot LOGO and dynamic boot screen； ² Support custom replacement of static wallpaper, dynamic wallpaper； ² Support the device to sleep regularly and enter the screen saver to save energy and reduce consumption； ² Support 8 languages to switch freely； ² Support a network cable Android and built-in computer Internet access function； ² Support microphone mixing function； ² Support four major system theme style switching, namely conference theme, education theme, technology theme, classic theme； ² The floating icon supports user-defined addition of 8 shortcut functions to the application menu； ² Support gestures to zoom in and out of images after freezing； ² Intelligently identify the signal source, and automatically jump into the port channel when an external signal is connected； ² Simple control panel, USB3.0*3 all channels follow, round power button - supports turning off the all-in-one machine, turning on and off the computer, and saving energy (you can select "three-in-one" in the settings menu)； ² Wireless screen sharing, multi-screen interaction, one-key screen projection, two-way control, to achieve content sharing between multiple devices； ² Support clicking on the left and right sidebars in any channel to expand the function menus, namely return, home page, task, annotation, signal source, side menu, the sidebar will be automatically hidden after 5 seconds without any operation in the expanded state； ² Support remote video conference; embedded integrated design of camera and array microphone, combined with application operation, support third-party video conference software and hardware, real-time, delay-free, high-quality transmission of conference data to easily realize remote communication； ✳ Note: Please use it under PC and install third-party video conferencing software applications； |
|
Other |
² Front expansion port: 3-way USB3.0 full-channel PC/Android sharing interface, TOUCH-USB, 1-way, HDMI interface 1-way, which is convenient for users to expand and use； ² The design of the front speaker outlet prevents the sound effect from being noisy and distorted due to the built-in； ² The high-performance infrared touch frame solution with anti-blocking and anti-stain functions is adopted, and the touch reception does not affect normal writing even after the single-point or multi-point infrared emission point is blocked.； ² Support wired LAN, wireless 2.4/5G WIFI network connection； ² It can be set to display and hide the floating icon and sidebar icon. The floating icon can be dragged to any position on the display screen, and the sidebar icon can be moved up and down after long pressing.； |
|
Body material |
Aluminum alloy front frame |
|
Front frame glass |
Physical toughened grade 7 explosion-proof glass, AG anti-glare treatment; |
|
Overall size（mm） |
1707.9（L）*97.7（W）*1035.1（H）with OPS |
|
Package size（mm） |
1865（L）220（W）1195（H）（Cover and tray box） |
|
Product weight |
56KG(NW)、68KG（GW） |
|
Total power |
≤ 300W（Without OPS，Sopport OPS Power ≤100W） |
|
Standby power |
≤0.5W |
|
Sound speaker |
Stereo sound, 2*15W high and low sound |
|
Input voltage |
100-240V~ 50/60Hz |
|
Solution |
Hi3751 V811 |
|
CPU |
Dual-core A73 and dual-core A53 ，1.5GHz |
|
GPU |
Quad-core MaliG51 |
|
RAM DDR |
4G |
|
ROM Storage |
32GB |
|
OS |
Android 8.0 |
|
Input port |
VGA * 1 |
|
VGA Audio * 1 |
|
|
AV IN * 1 |
|
|
HDMI* 2 |
|
|
Ypbpr IN* 1 |
|
|
MIC IN* 1 |
|
|
Output port |
Earphone* 1 |
|
SPDIF* 1 |
|
|
HDMI OUT* 1 |
|
|
Other ports |
